Hydraulic Button Battery Crimping Machine for All Kinds of Coin Cells
AOT-MSK-110 is a new design and CE Certified manualcoin cell crimper machine with lighter weight and a smaller footprint. The crimping machine is suitable for sealing various types of coin cells such as CR2032,CR2025,and CR2016 with included die. It can also crimp CR2325, CR2450, AG3, AG5 and other special size cases with optional die sets.
SPECIFICATIONS:
|
Features |
Heavy duty steel frame PTFE Anti-Corrosion Core prevents coin cells from being short-circuited |
|
Crimping Die |
Optional die available from product option for crimping CR20XX, CR12XX, CR23XX, CR24XX, AG3, AG5 |
|
Pressure |
Max. 8 metric Tons hydraulic pump with automatic pressure relief Max.200 Kg/cm2 on CR20XX series coin cell |
|
Warranty |
One year limited manufacturer warranty with lifetime support. |
|
Product Dimensions |
223mm X 170mm X 325mm |
|
Compliance |
CE Certified |
|
Net Weight |
25 kg |
|
|
Attention: The built-in small hydraulic pump is not designed for holding high pressure. The pressure inside will be released gradually after reaching 50~80 Kg/cm^2, (which is sufficient for disassembling the coin cell). |
